CCD Digital Auto Feeding Flatbed Die Cutter Have Cutting and Creasing Tool Half/Kiss-Cut for Synthetic Paper, Label, Self-Adhesive Material and Thin PVC
HomeHome > Products > Half-cut Die Cutting Machine > CCD Digital Auto Feeding Flatbed Die Cutter Have Cutting and Creasing Tool Half/Kiss-Cut for Synthetic Paper, Label, Self-Adhesive Material and Thin PVC
CCD Digital Auto Feeding Flatbed Die Cutter Have Cutting and Creasing Tool Half/Kiss-Cut for Synthetic Paper, Label, Self-Adhesive Material and Thin PVC

CCD Digital Auto Feeding Flatbed Die Cutter Have Cutting and Creasing Tool Half/Kiss-Cut for Synthetic Paper, Label, Self-Adhesive Material and Thin PVC

Overview Auto Feeding Flatbed Die Cutter Detailed introduction --AFC4866 Product Description Advantage:1.CCD Sensor Auto
Basic Info
Model NO. Auto Flatbed cutter
Computerized USB Direct Connection to The Computer Corel Draw/
Automatic Grade Automatic
Application Paper Packaging Materials, Stickers Products, Soft Materials, Films,Less Than 0.3 mm PVC
Software Dragon Cut & Corel Draw & Adobe Illustrator
Positioning CCD Sensor Auto Positioning
Cutting Material Soft Materials, Films,Less Than 0.3 mm PVC
Transport Package Wooden Case
Specification 2390mm*1005mm*1235mm
Trademark Saga & Customized
Origin China
HS Code 84411000
Production Capacity 1500
Product Description

Auto Feeding Flatbed Die Cutter Detailed introduction

--AFC4866

Product Description

Advantage:1.CCD Sensor Auto Positioning

2.Pneumatic automatic paper feeding system, stacking up to 600 sheets;

3.Scanning speed 5-10 seconds;Paper feeding speed up to 12 pieces / minute;

4.Have 960g cutting pressure, industrial grade carriage, a wider range of cutting materials;

5.Optional blade module suits various media cutting demands.

6.Aluminum alloy fuselage structure, sheet metal bracket, stable use;

7.USB direct connection to the computer Corel Draw/ Illustrator Plug-in

8.Highly sensitive touch capacitive screen with mechanical button operation is more precise and faster;

9.Digital Servo system, more accurate, more stable, lower noise;

10.The camera automatically patrols the edge and cuts at high speed;

11.Different sizes of models,wider effective cutting range ;

12.The edge can be as small as 5mm, making full use of it and saving paper more environmentally friendly.Application:
A variety of tools to quickly cut a variety of different materials:Soft materials, films, various types of stickers, cardboard,less than 0.3 mm PVC

Detailed Photos

CCD Digital Auto Feeding Flatbed Die Cutter Have Cutting and Creasing Tool Half/Kiss-Cut for Synthetic Paper, Label, Self-Adhesive Material and Thin PVC

Product Parameters

Model NameSG-AFC4866
Cutting control systemDigital servo system
Positioning sensor typeDigital CCD Camera
Scanning code typeMaker Points&QR Code
Sheet feedingUp to 500pcs depends on thickness of the paper
Scanning speed5-10S
Maximum sheet size485mmX660mm
Single cutting sizeize480mmX330mm
Maximum cutting speed600mm/s
Maximum cutting force750GSM
Maximum creasing weight1500GSM
Minimum cutting size5mm
Control panelLCD touch with keys
Actual dimensions2390mm×1005mm×1235mm
Package dimensions1755mm×1120mm×675mm(Cutting Platform)
915mm×865mm×1400mm(Feeding Platform)
Net/Gross weight136kg/234.6kg
Software and compatiblityDragon CutTM ,PC only,compatible for Windows7,8,10(USB interfaces)Corel Draw/ Illustrator Plug-in, PC only (USB interfaces)
Voltages100V~240V 50/60 Hz
Power1.1KW
